SPEC
neck type    SRFF6 for Multi Scale 5pc neckJatoba/Bubinga
top/back/body    Ash body
fretboard    Rosewood
fret    Medium frets
number of frets    24
bridge    Mono-rail V bridge (16.5mm string spacing)
neck pickup    Bartolini® BH1 neck pickupPassive
bridge pickup    Bartolini® BH1 bridge pickupPassive
equaliser    Ibanez Custom Electronics 3-band eq w/Eq bypass switch (passive tone control on treble pot) & Mid frequency switch
factory tuning    1C, 2G, 3D, 4A, 5E, 6B
string gauge    .032/.045/.065/.080/.100/.130
hardware color    Cosmo black

NECK DIMENSIONS
Scale :    901.7mm/35.5" - 854.7mm/33.6"0
a : Width    54NUT
b : Width    8324
c : Thickness    19.51
d : Thickness    2312
Radius :    400

CONTROLS

FREQUENCY RESPONSE
