SPECS

• neck type
• SRMS5 for Multi Scale5pc Jatoba/Walnut neck
• top/back/body
• Poplar Burl topOkoume body
• fretboard
• Bound Panga Panga fretboardAcrylic special inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• MR5S bridge
• string space
• 16.5mm
• neck pickup
• Bartolini® BH2 neck pickupPassive
• bridge pickup
• Bartolini® BH2 bridge pickupPassive
• equalizer
• Ibanez Custom Electronics 3-band EQ w/ EQ bypass switch (passive tone control on treble pot) & 3-way Mid frequency switch
• factory tuning
• 1G,2D,3A,4E,5B
• strings
• D'Addario® EXL170-5SL
• string gauge
• .045/.065/.080/.100/.130
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 901.7mm/35.5" - 864.0mm/34.0"
  • a : Width
  • 45mm at NUT
  • b : Width
  • 68mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 23mmat 12F
  • Radius :
  • 305mmR

CONTROLS

FREQUENCY RESPONSE

Features

Panga Panga fretboard

Panga Panga features a beautiful wood grain which produces a tight low and mid range, along with a sharp attack on high end.

Poplar Burl top / Okoume body

A stunning Poplar Burl top and an Okoume body provide bright and solid sound.

MR5S bridge

The MR5S bridge has adjustable saddles for variable string spacing by +/- 1.5mm, answering every bassist’s specific string spacing needs.

Ibanez Custom Electronics 3-band EQ w/EQ bypass switch & Mid frequency switch

Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
Precision tonal control, including a switch to choose passive-only operation. When the EQ bypass is activated, the treble tone control knob becomes the global tone control for the passive circuit.

Bartolini® BH2 pickups

The Bartolini® BH2 pickups provide a tight bottom-end, punchy mid-range, and smooth response. The dual-coil style configuration maximizes articulation and a long blade pole piece widens the magnetic field, providing balanced string-to-string pickup response.

Multi scale

Equalized tension helps to create a more "alive", open tone. But the design also improves player comfort. The multi scale construction ergonomically coordinates with the way a player's hand angles as it moves up and down the neck, facilitating quick, comfortable playing action.

SRMS for Multi Scale 5pc Jatoba/Walnut neck

Two of the most rigid and musical hardwoods set against one another to provide a thin neck with reliable long-term harmony.
