SPEC
neck type    ATZ S-TECH WOOD 1pc Roasted Maple neck
top/back/body    Alder body
fretboard    S-TECH WOOD Roasted Maple fretboardBlack dot inlay
fret    Jumbo Stainless Steel fretsPrestige fret edge treatment
number of frets    22
bridge    Wilkinson®-Gotoh® VSVG tremolo bridge
string space    10.8mm
neck pickup    DiMarzio® The Cruiser® (H) neck pickupPassive/Ceramic
middle pickup    DiMarzio® The Cruiser® (H) middle pickupPassive/Ceramic
bridge pickup    DiMarzio® The Cruiser® (H) bridge pickup
factory tuning    1E,2B,3G,4D,5A,6E
strings    D'Addario® EXL110
string gauge    .010/.013/.017/.026/.036/.046
nut    Bone
hardware color    Chrome

NECK DIMENSIONS
Scale :    648mm/25.5"
a : Width    40.5mm at NUT
b : Width    56mm at 21F
c : Thickness    21mm at 1F
d : Thickness    23mm at 12F
Radius :    305mmR

SWITCHING SYSTEM

CONTROLS
