PRODUCT OVERVIEW
neck type PGMM Maple neck
top/back/body Poplar body
fretboard Treated New Zealand Pine fretboardWhite dot inlay
fret Medium frets
number of frets 24
bridge Ibanez F106 bridge
neck pickup Infinity R (H) neck pickupPassive/Ceramic
bridge pickup Infinity R (H) bridge pickupPassive/Ceramic
factory tuning 1E,2B,3G,4D,5A,6E
string gauge .010/.013/.017/.026/.036/.046
nut Plastic
hardware color Black
Scale : 564mm/22.2"
a : Width 41mm at NUT
b : Width 56mm at 24F
c : Thickness 19.5mm at 1F
d : Thickness 21.5mm at 12F
Radius : 400mmR
SWITCHING SYSTEM
CONTROLS
